Technical features
– 8 Axis Servo controlled CNC
– Fully automated feeding, carrying, positioning, cutting and transferring units
– Drill, Mill and slot on all 4 sides
– Pneumatic gripper for accurate positioning of the profile
– Horizontal and vertical clamping of the profile
– Automatic conveyor unit with the loading capacity of 7 profiles

– ø50 mm diameter Servo controlled saw blade

– 30° to 150° with the accuracy of -/+ 0.1°
– Windows based PC and 15.6’’ LCD touch screen monitor
– Remote desktop connection and providing technical support
– User friendly interface software that is compatible with most CAD programs
– Ability to perform milling and cutting operations at the same time
– Automatic frame and sash profile recognition system
– Automatic profile width and height dimension control system
– Automatic lubrication system
– Low pressure control for saw blade safety operations
– LED interior lighting
– Barcode Printer

Additional information
Weight 3070kg
